• On the basis of optical engineering, optical technologies for sensing mechanical motion, spectroscopic properties, and other physical/chemical characteristics are investigated. Moreover, using semiconductor micro/nano-fabrication technology, integrated micro-optical sensors, micro/nano optical systems, optical micro-electro-mechanical systems (MEMS) are studied. Micro laser scanner for display, deformable mirror for telescope, optical displacement encoder, and fluorescent analysis system are the examples of research topics.

Optical design, Optical industries, Industries relating to semiconductor micro fabrication and MEMS, optical telecommunications, etc.

• Most innovations have been triggered by advent of new materials. We focus on to explore new inorganic materials and their synthesis routes on the basis of our knowledge about the material design and various materials processing technologies. We develop proton conducting phosphate glasses working at intermediate temperatures and narrow gap oxide semiconductors applicable in visible and NIR regions. Thin-film solar cells, fuel cells using those materials are also developing.

We focus on oxide semiconductors and proton conducting electrolytes and electrodes in order to apply them in solar cells, fuel cells, light-emitting devices. But, applicable area of our technologies is not limited in those applications.

• We are developing a new continuous flow type process for supercritical reactions. Under the supercritical state, the organic molecules and metal salt aqueous solutions are miscible and water molecule works as an acid/base catalyst which leads to rapid reactions. In order to apply such new reaction fields to an industrial process, it is necessary to establish the process design basis by understanding phenomena in the reaction fields, on the basis of phase equilibrium, flux and reaction kinetics theory. So while developing a process, we are doing research for the establishment of the process design basis.

Examples are a process for the synthesis of organic modified nanoparticles (MPs), a process for the pretreatment and solubilization of biomass in the supercritical/subcritical water and a process for the refinery of heavy oil in the supercritical water.

• Toward the ultimate performances of image sensors, advanced research activities are being conducted that cover a wide range of technology fields from cleanroom infrastructure, materials, process equipment, process, device, circuit, assembly, signal processing, measurement/evaluation and reliability. Following technologies have been successfully commercialized:
• A fast and accurate measurement technology of electrical characteristics for over 1 million transistors
• A wide dynamic range CMOS image sensor technology capturing images over five decade brightness ranges
• An ultra-fast CMOS image sensor technology with 10 million frames/sec

Followings are available for industry collaborators:
A. 200mm-diameter-wafer silicon device fabrication utilizing the ultra-clean facility including wafer mutual fabrication processing between device manufacturers.
B. Process technology development and various kinds of analyses.
C. Development of new image sensors.

• Scanning tunneling microscope (STM) and atomic force microscope (AFM) are among a few microscopes which enable a direct observation of atomic scale structures of materials. If compared with other electron microscope like transmission electron microscope (TEM), the energy of the electron used for STM is very low that has a big advantage of low damage for sample. Thus STM and AFM are regarded as the most important tools to characterize materials in nanotechnology. The research is now developing from a mere observation of the shape of material to the characterization specific properties of materials with an atomic scale resolution. These properties include spin and molecule vibration; well established techniques like ESR/NMR and infrared-spectroscopy requires more than billions of molecules to obtain data, while STM can obtain these data for a single molecule.
• We are interested following issues and like to have a collaboration with industrial companies.
• 1. Molecule-scale morphological characterization of soft-material, polymers and bio material.
• 2. Site specific vibration spectroscopy of molecules with an atomic resolution.
• 3. Single spin detection with ESR-STM method
• 4. Developing atom-scale characterization tool

• The main research subject of our group is developing material purification methods, crystal growth methods and detector fabrication technologies for compound semiconductor radiation detectors. Our group intensely studies a compound semiconductor, thallium bromide (TlBr), for fabrication of gamma-ray detectors for the advanced radiation applications. The attractive physical properties of TlBr lie in its high atomic number (Tl: 81, Br: 35), high density (7.56 g/cm3) and wide bandgap (2.68 eV). Due to the high atomic number and high density, TlBr exhibits high photon stopping power. The wide bandgap of TlBr permits the device low-noise operation at and above room temperatures.

Our group focuses on development of compound semiconductor radiation detectors for advanced radiation applications including ultra-high resolution PET systems, ultra-high resolution SPECT systems, photon counting CT systems and Compton cameras. We hope to conduct collaborative research with a willing company for a practical application of this technology in industry.
